Lumag VH500PRODA 500kg Professional Petrol Track Barrow with a Diesel Engine

Available on backorder

The Lumag VH500PRODA track barrow is a professional quality diesel-powered track barrow with self-loading shovel. The machine is fully hydrostatic and robustly made. This machine was made with durability and ease of use in mind. It is propelled by a top of the range hydraulic pump and has a handy stand plate. This machine will offer years of great service and comes with a 2-year warranty.

Lumag VH500PRODA 500kg 6.5 HP Diesel Track Barrow / Dumper with Self Loading Shovel

The Lumag VH500PRODA track barrow is a professional quality diesel-powered track barrow with self-loading shovel. The machine is fully hydrostatic and robustly made. This machine was made with durability and ease of use in mind. It is propelled by a top of the range hydraulic pump and has a handy stand plate. This machine will offer years of great service and comes with a 2-year warranty.

These professional dumpers are ideal for transporting materials such as sand, salt, gravel, building materials, garden waste, stone, wood etc. The great advantage is their with a width, with a width of approximately 84 cm these dumpers should fit through the majority of gates and narrow paths. Emptying these is easy for bulk and piece goods can be emptied using a hydraulic tipping skip.

They tracked and offer very low ground pressure. The rubber tracks provide excellent grip which makes these dumpers particularly good for use on steep slopes and rough/uneven terrain. The hydraulic drive ensures trouble-free operation as there is no wear on cables, pulleys, couplings or belts. It's self-loading and features a hydraulic tip.

Specifications

• Engine - 1-cylinder 4-stroke OHV LONCIN Deisel engine
• Displacement - 349cc
• Power - 6.5 HP or 4.9 kW
• Max speed - 3600RPM
• Start-up facility - Reverse starter
• Drive - Hydraulic
• Steering - Fully hydraulic / control valve
• Tipping container (LxWxH) - 855 x 680 x 550 mm
• Payload max. - 500 Kgs
• Volume Trough - approx. 0.25 m3
• Tilting device - hydraulic, tiltable forward
• Hydraulic pumps - 2x10l/min (at 3,000 rpm)
• Working pressure max - 180 Bar
• Hydraulic motor - Max 720 Nm at 180 bar
• Working speed (infinitely) Forward /Reverse - max. 4.5 / max. 3.2 km/h
• Ground clearance - 65mm
• Max climbing ability- 15°
• Dimensions caterpillar - H/255, W/180 mm
• Dimensions (LxWxH) - 1890 x 850 x 1224 mm
• Packaging dimensions (LxWxH) - 1550 x 850 x 1250 mm

Warranty

All Tracked Barrows are covered by a 2-year domestic warranty (1 year for commercial).

Technical Specification:

Specification
